Iota Engineering DLS/M-12V-15A/120V 12V 15A Power Converter & Battery Charger
The Iota DLS/M-12V-15A/120V provides clean, regulated 12VDC power and dependable 15‑amp battery charging for RV, solar, backup, and industrial systems. This model is part of Iota’s proven DLS series, known for long-term reliability, low ripple output, and stable voltage regulation for sensitive electronics.
Key Features
- Correct model: DLS/M-12V-15A/120V
- 12VDC output with 15A continuous charging capability
- Automatic three‑stage charging when paired with IQ module
- Exceptionally clean DC output for electronics and battery banks
- Built‑in overload, thermal, and short‑circuit protection
- Reliable Iota Engineering construction for continuous-duty applications
Applications
- RVs and campers
- Off‑grid solar systems
- Battery backup and telecom systems
- 12V industrial loads and power supplies
Technical Specifications
| Model | DLS/M-12V-15A/120V |
| Input Voltage | 108–132 VAC, 50/60 Hz |
| Output Voltage | 13.4 VDC nominal |
| Output Current | 15 Amps continuous |
| Max Output Power | ~200 Watts |
| Line Regulation | ±1% |
| Load Regulation | ±1% |
| Ripple & Noise | <50mV RMS typical |
| Protection | Current limiting, thermal, short‑circuit |
| Operating Temp | 0°C to 40°C |
| Dimensions | 7.3" L × 6.5" W × 3.4" H |
| Weight | ~4.0 lbs |
| Certifications | UL Listed, FCC Class B |
| IQ4 Compatible | Yes (optional module) |
What’s Included
- Iota DLS/M-12V-15A/120V Charger
- AC power cord
- User documentation
