Product Description
Mercotac 430-SS Brushless Slip Ring
The Mercotac 430-SS is a high-performance brushless slip ring designed for applications requiring both sensitive signal transfer and reliable power delivery. Using Mercotac’s liquid-metal technology, the 430-SS provides exceptionally low resistance, low noise, and long service life compared to traditional brush-type slip rings.
Key Features:
- Four conductors: 2 circuits rated 4A and 2 circuits rated 30A (250V max)
- Stainless-steel ball bearing (SS designator) for enhanced corrosion resistance in wet or harsh environments
- Durable, compact, and lightweight metal construction
- Ultra-low contact resistance (<1 mΩ) and high circuit separation (>25 MΩ) for clean signal transfer
- Maintenance-free operation with long service life
- Rated for up to 1200 RPM and operating temperatures from -20°F to 140°F (-29°C to 60°C)
- IP51 protection rating when used with optional boot kit
Common Applications:
- Heated rollers requiring both thermocouple signal and heater power
- Industrial automation and robotics
- Medical equipment
- Packaging and labeling machinery
- Rotary sensors and instrumentation
Technical Specifications (430‑SS)
- Conductors: 4
- Voltage Rating: 250V AC/DC
- Current Rating: 2@4A and 2@30A
- Body Material: Anodized Aluminum
- Bearing Type: Stainless Steel (SS model)
- Max Rotational Speed: 1200 RPM
- Max Rotational Torque: 400 gf‑cm
- Operating Temperature: -20°F to 140°F
- Contact Resistance: <1 mΩ
- Circuit Separation: >25 MΩ
- Max Frequency: 100 MHz
Important Shipping & Compliance Information
Item contains MERCURY... therefore shipping to some destinations located within the continental US is not permitted. Contact us before purchase if you have questions. Hurricane Wind Power will not be responsible for misuse of this product.
Transported by UPS Ground to the US lower 48 only. No special handling or hazardous designation is required when shipped by ground.
Due to the US ban on the Sale or Distribution of Specific Mercury-Added Products, we are unable to ship this product to Connecticut, Rhode Island, or Louisiana.
