Product Description
SRNE ABP4865U140-H 6500 Watt 48 Volt Split-Phase Inverter/Charger
The SRNE ABP4865U140-H is a high-capacity 6.5KW hybrid inverter/charger designed for residential, commercial, and off-grid applications requiring true 120/240VAC split-phase output. With a wide 150–450VDC MPPT input range and 5000W PV capacity, this unit delivers strong solar charging performance and reliable AC power for demanding loads.
Key Features:
- 6500 Watt continuous output
- 5000 Watt MPPT solar input
- 48 Volt DC battery input
- 120/240VAC split-phase output
- Wide 150–450VDC MPPT operating range
- Hybrid inverter/charger design
- High-efficiency power conversion
- Advanced protections and smart monitoring
Specifications:
- Rated Power: 6500W
- Battery Voltage: 48VDC
- AC Output: 120/240VAC split-phase
- MPPT Input Range: 150–450VDC
- Max PV Input: 5000W
- Estimated Weight: 52 lb (62 lb boxed)
- Estimated Dimensions: 23” × 16” × 8” (27” × 20” × 12” boxed)
- Topology: Hybrid inverter/charger
- Cooling: Intelligent forced-air cooling
- Protection: Overload, over-temp, short-circuit, surge
Applications: Off-grid homes, cabins, workshops, commercial systems, and any installation requiring 120/240V split-phase power.
Includes: ABP4865U140-H inverter/charger and user documentation.
Shipping: Free UPS Ground shipping when applicable. Due to weight and size, some destinations may require LTL freight. If LTL is required, we will contact you before shipment to arrange freight billing.
